Motion View Series

When it comes to measuring systems with big measuring ranges, limited space at the operation site is often a problem. The solid, stable video measuring systems of the Motion View series are the perfect solution for this. Their special design of a moving portal in the X/Y/Z axes allows the workstage to be static during the whole measuring procedure, permitting big measuring ranges to be realized without occupying a large space that the usual gantry bridge style machines require. A comprehensive range of capacity options starts with 400 x 600 x 300 mm and goes up to 1700 x 2000 x 300 mm. Another benefit of this design is the fixed workstage which can support and measure not only heavy workpieces but also smaller components without the need for fixturing.

Product Features
  • Models: 600, 800, 1000, 1200, 1500, 1700, 2000

  • Robust design made of granite with moving portal

  • CNC controlled drive system

  • Telecentric LED transmitted light and programmable segmented LED surface ring light

  • Autozoom objective 0.7-4.5x with additional coaxial surface light

  • 1.3 MP B/W CMOS camera

  • TOPAS MULTI SOFT measuring software
